# Kepler-51 b: Stress-Testing a Super-Puff with TESS
<!-- RESEARCH-IDENTITY-START -->
**Independent research report by [Biswajit Jana](https://biswajit1999.github.io/Biswajit_Jana.github.io/)** · [Live report](https://biswajit1999.github.io/kepler-51b-exoplanet-report/) · [ORCID](https://orcid.org/0009-0002-2411-1891) · [Complete research portfolio](https://biswajit1999.github.io/Biswajit_Jana.github.io/research/exoplanets/)
<!-- RESEARCH-IDENTITY-END -->





<!-- TARGET-IDENTITY-START -->
<p align="center">
  <img src="assets/artist_concept.webp" alt="Artist's interpretation of Kepler-51 b near its host star" width="900">
</p>

<p align="center"><em>AI-generated artist's interpretation informed by the measured system properties; not a direct image.</em></p>

**Super-puff · weak TESS support · null-result discipline**

An iconic ultra-low-density planet used as a transparent null-result case: this TESS sector does not pass the report’s predeclared transit-support threshold.
<!-- TARGET-IDENTITY-END -->
<p align="center">
  <img src="figures/kepler51b_tess_transit.png" alt="Phase-folded real TESS transit light curve of Kepler-51 b" width="760">
</p>


**[Open the full report](https://biswajit1999.github.io/kepler-51b-exoplanet-report/)** — the live GitHub Pages version.

## Data sources

- **System parameters** — the saved `pscomppars` row from the [NASA Exoplanet Archive TAP service](https://exoplanetarchive.ipac.caltech.edu/TAP/sync?query=select+pl_name%2Chostname%2Cra%2Cdec%2Cpl_orbper%2Cpl_tranmid%2Cpl_trandur%2Cpl_rade%2Cpl_bmasse%2Cpl_eqt%2Cpl_orbsmax%2Csy_dist%2Csy_tmag%2Cst_teff%2Cst_rad%2Cst_mass%2Cdisc_year%2Cdiscoverymethod%2Cdisc_refname%2Cdisc_pubdate%2Cdisc_facility+from+pscomppars+where+pl_name%3D%27Kepler-51+b%27&format=csv).
- **Observed photometry** — unmodified MAST file `tess2019198215352-s0014-0000000027846348-0150-s_lc.fits`, TESS Sector 14, DOI [10.17909/t9-nmc8-f686](https://doi.org/10.17909/t9-nmc8-f686). This is a real SPOC reduced light curve, not simulated data.
- Exact URLs, IDs, retrieval date, and SHA-256 checksum are in [`data/SOURCE.md`](data/SOURCE.md).

## Reproduce the analysis

```bash
pip install -r requirements.txt
python scripts/analyze_transit.py
python scripts/analyze_multisector.py
pytest tests/ -v
```

The script keeps finite `QUALITY == 0` cadences, normalizes `PDCSAP_FLUX`, and applies one symmetric robust outlier rule. A local linear null is compared with a circular quadratic-limb-darkened transit. The archive period and predicted phase are retained, while midpoint, radius ratio, impact parameter, baseline, and baseline slope are fitted inside a bounded window. The limb-darkening coefficients and scaled semi-major axis are fixed and disclosed in the CSV.

## What the corrected fit shows

| Quantity | Result |
|---|---:|
| TESS sector | 14 |
| Cadences in fitted window | 1038 |
| Transit support | not supported |
| Midpoint correction | +3.478 h ± 20.36 min |
| Model mid-transit depth | 10830.9 ± 2770.3 ppm |
| Radius ratio Rp/Rs | 0.09728 |
| Fitted / published duration | 6.211 / 5.797 h |
| Linear null χ² / dof / BIC | 954.33 / 1036 / 968.22 |
| Transit χ² / dof / BIC | 938.31 / 1033 / 973.04 |
| ΔBIC (null − transit) | -4.82 |

The best transit-shaped profile is not supported over the local linear null (ΔBIC = -4.8). Its fitted depth and timing are therefore exploratory optimizer outputs, not a transit measurement. A fitted timing correction can diagnose ephemeris drift, but this single-sector fit is not a replacement for a global transit-timing analysis.

<!-- MULTISECTOR-UPGRADE-START -->
## Multi-sector robustness and correlated noise

The archive prediction was timing-adjusted independently in 1 fitted sector(s) (S14), of which 0 meet Delta BIC >= 10 from 2 committed files; 1 lacked adequate fixed-window sampling. Formal depth errors were inflated by sqrt(max(reduced chi-square, 1)) times the residual time-averaging beta factor (observed range 1.04-1.04). No fitted sector reaches the Delta BIC >= 10 support threshold, so no combined transit depth or sector-consistency claim is reported. These scaled errors address underestimated scatter and short-timescale correlation, but they are not a full Gaussian-process or physical limb-darkened transit fit.

<p align="center"><img src="figures/kepler51b_multisector_transits.png" alt="Independent sector transit fits for Kepler-51 b" width="760"></p>

<p align="center"><img src="figures/kepler51b_depth_consistency.png" alt="Sector depth consistency for Kepler-51 b" width="760"></p>

<p align="center"><img src="figures/kepler51b_noise_diagnostics.png" alt="Residual RMS time-averaging diagnostic for Kepler-51 b" width="760"></p>

The per-sector table is in [`figures/multisector_statistics.csv`](figures/multisector_statistics.csv). Regenerate all three figures with `python scripts/analyze_multisector.py`.
<!-- MULTISECTOR-UPGRADE-END -->

## System context

- Radius: 7.10 Earth radii
- Mass: 2.10 Earth masses
- Orbital period: 45.154000 days
- Transit duration: 5.797 hours
- Semi-major axis: 0.2514 AU
- Equilibrium temperature: 543 K
- Host: Kepler-51 · distance 783.83 pc
- Discovery: 2012 by Transit (Kepler)

## Limitations

- The orbit is assumed circular and the quadratic limb-darkening coefficients are fixed representative values; they are not atmosphere-grid interpolations.
- The scaled semi-major axis is derived from the saved composite semi-major axis and stellar radius; their uncertainties are not propagated.
- Midpoint freedom corrects accumulated ephemeris error but introduces a bounded timing search. ΔBIC, not a naïve one-parameter p-value, is used as the support gate.
- PDCSAP processing, dilution, stellar variability, transit-timing variations, and long-timescale covariance can still bias the inferred geometry.
- Radius ratio, impact parameter, and fixed limb darkening are correlated. Published global fits with physical priors and simultaneous detrending remain authoritative.

## Repository structure

```text
README.md
index.html
requirements.txt
data/                       unmodified TESS FITS + NASA row + SOURCE.md
scripts/analyze_transit.py  timing-adjusted limb-darkened transit fit
figures/                    generated plot + summary_statistics.csv
tests/                      real-data regression tests
.github/workflows/tests.yml CI on every push and pull request
LICENSE                     MIT
```

## References

1. [Steffen et al. 2013](https://ui.adsabs.harvard.edu/abs/2013MNRAS.428.1077S/abstract) — discovery reference as listed by the NASA Exoplanet Archive.
2. Ricker, G. R. et al. (2015), *Transiting Exoplanet Survey Satellite (TESS)*, JATIS 1, 014003, [doi:10.1117/1.JATIS.1.1.014003](https://doi.org/10.1117/1.JATIS.1.1.014003).
3. TESS Team, *TESS Light Curves — All Sectors*, MAST, [doi:10.17909/t9-nmc8-f686](https://doi.org/10.17909/t9-nmc8-f686); Sector 14 used here.
4. [NASA Exoplanet Archive](https://exoplanetarchive.ipac.caltech.edu/), `pscomppars` TAP row retrieved 2026-08-15.
